Supply – DC
Holding Force – 20Kgf
Size (mm) – 51 X 70 x 85
Surface Mounting
Flat Keeper Plate
Voltage – 24VDC or 48VDC
Nominal Power @ 20°C – 0.6W
Protection Class – III
Protection Rating – IP42 EN60529
Weight – 560g
Temperature Class – B
Temperature Range – -5°C / +40°C
Electrical Connection – Terminal Board
Box Colour – Grey RAL 9002 painted steel
Conformity with Standards – NF S 61 937 1&2, EN1155:1997 + A1:2002 + AC:2006
AC916ME27
Specification
Rating/Power
Standard voltage – 24V DC
100% – 0.6W
Datasheet
Please click for datasheet
